Phosphate from agriculture

Run-Off and Leaching
The dominant soil type in the area of the study is deep heavy clay. It is very fertile being classified in the main as grade 3A soil with some areas of grade 2 in the valley bottoms. Clay soil is absorbent, being able to absorb sometimes up to 60% of its own weight of water but the rate at which it absorbs water is very slow. These properties have a number of consequences:

• Heavy storms can cause sudden flash floods when the rate of absorbance into the soil is too slow to cope with the rainfall. Fine grains of the surface clay are often washed off (together with any soluble nutrient) giving the water in a typical milky appearance.
• During periods of heavy rain, water that enters the soil tends to run laterally through the top layers of clay into any nearby ditch, taking with it some of the soluble nutrients.
• Rainwater is best able to penetrate the clay soils when the soil is well vegetated, particularly if some of the plants have long roots. Thus run-off from permanent grassland is typically much less than run-off from cultivated land, particularly between harvest and subsequent sowing.
• As water is absorbed through clay, dissolved nutrients such as nitrate and phosphate are gradually removed and held in the soil.
• Clay soils tend to retain nutrients more effectively than sandy soils releasing them more slowly into ditches over a longer period of time.
• Run-off is greatest from compacted soils. For this reason DEFRA advises farmers to break up the surface of clay soils immediately after compacting activities such as harvesting. This is particularly noticeable in this region after maize harvests.

Seasonal variations in river phosphate concentrations
This study, and also the measurements routinely made by Wessex Water and the Environment Agency show a seasonal variation in phosphate concentrations. These tend to peak in the summer. The main cause of this is very probably the variation in river levels which dilutes the phosphate i winter when levels are generally higher. No evidence appears to have been published on the seasonal variation in the absolute quantities of phosphate leaching into the rivers. This is some what surprising given that water levels are read automatically by the dranage board at many of the sample points and are available online.

The seasonal variation in phosphate is further complicated by the complexity of the operation of the drainage processes in the Levels catchment. These processes have two basic aims; to stop the flooding of population centres on the one hand and to stabilise the level of the water table on the other. This means that, in winter, the water, and hence the phosphate, in the main rivers normally tends to flow largely uninterrupted into the Bristol Channel. (This routine may be temporarily changed in the event of a flood during which excess water may be diverted onto the Levels.) In summer, however, the drainage system is designed retain water on the Levels with the result that nutrients such as phosphate are concentrated there,

DEFRA guidance on farming near watercourses
DEFRA has long recognised the importance of field margins both for reducing run-off and also for reducing the leaching of soluble nutrients such as phosphate by water running through the soil. The gist of its guidance (link on he right) is that fields adjacent to watercourses should have a margin of 6 m, particularly if the field slopes towards the watercourse, and also particularly if slurry is used as a fertiliser. Very few farms observe this advice but what is very clear from our results is that where they do follow the advice, the concentrations of phosphate reaching the rivers is very low.

Recent farming patterns in Ash and Martock Parishes
We have seen some significant changes in farming patterns in the two parishes in recent years. One trigger for these changes has been the steady increase in the cost of inputs such as increasingly sophisticated and large machinery. This has led increasinly to the contracting out of the production of many crops to specialist farmers who have invested heavily in machinery for particular crops, such as maize or potatoes. An observed, though not universal, casualty of this trend has been the 6m field margins which this study suggests has had a significant impact on phosphate pollution levels.

Of particular significance locally has been the recent establishment in the Parish of Ash of a large intensive dairy unit. Most of the land in both parishes is now dedicated to producing feedstock for this unit, mainly in the form of cultivated grass and maize. The map below shows that the uptake of different schemes to replace the Basics Support Grant that farmers received under the Common Agricultural Policy. The strikingly low uptake of any of these schemes in the two parishes suggests that farmers here, instead, have chosen contracts to supply the dairy.
